Lab 1 - Compute Pipeline

What is a GPU

Graphics Processing Unit
Help the Central Processing Unit (CPU)
Initially for the calculation of graphisms
More and more for other things.

Why a GPU ?

Optimized for parallel computing:
- Max cores in a CPU: 128 (very expensive)
- cores in a GPU: thousands
The same processing on a large number of data

How to use the GPU?

3 manufacturers for computers:
- Intel
- AMD
- NVidia
Many API:
- DirectX: Microsoft
- Metal: Apple
- OpenGL/Vulkan: Open
- CUDA: NVidia Compute API
- OpenCL: Open Compute API
- WebGPU

Vulkan

Modern API: Successor of OpenGL
Open and “Cross-plateform” (not so much on MacOS)
Highly explicit API
Graphics and Compute

WebGPU

One API to Rule them All
Designed for the Web and for Standalone Application
Use preferred API on each platform
More learnable than Vulkan

Without GPU: Python Loop

import numpy as np
import time

# Helper class to measure execution time
class Timer:
    def __init__(self, msg: str):
        self.msg = msg

    def __enter__(self):
        self.start = time.perf_counter()

    def __exit__(self, exc_type, exc_value, traceback):
        print(f"{self.msg}: {time.perf_counter() - self.start}")

# Input Data
n = 4194240
numpy_data = np.full(n, 3, dtype=np.int32)

with Timer("for in range loop"):
    res = []
    for x in numpy_data:
        res.append(x * x)

Without GPU: numpy

with Timer("numpy operation") as rep:
    res = numpy_data * numpy_data

Compute Pipeline

Use WebGPU with python

pip install wgpu

Get a Logical Device

from wgpu import gpu

adapter = gpu.request_adapter_sync(power_preference="high-performance")
device = adapter.request_device_sync()

Buffers

Create Buffer

from wgpu import BufferUsage

# input data
buffer0 = device.create_buffer_with_data(data=numpy_data, usage=BufferUsage.STORAGE)

# for the output
buffer1 = device.create_buffer(
      size=numpy_data.nbytes,
      usage=BufferUsage.STORAGE | BufferUsage.COPY_SRC,
)

Buffer contains only bytes No info on how to interpret them

Bind Group Layout

from wgpu import ShaderStage, BufferBindingType

bind_group_layout = device.create_bind_group_layout(
    entries=[
        {
            "binding": 0,
            "visibility": ShaderStage.COMPUTE,
            "buffer": {"type": BufferBindingType.read_only_storage},
        },
        {
            "binding": 1,
            "visibility": ShaderStage.COMPUTE,
            "buffer": {"type": BufferBindingType.storage},
        },
    ]
)

Describe the bindings needed in the Bind Group used by the compute operation

Compute Pipeline

# Load the source code to execute on the GPU
with open("compute.wgsl") as file:
    shader_source = file.read()

shader_module = device.create_shader_module(code=shader_source)

# A Pipeline may use multiple Bind Group
pipeline_layout = device.create_pipeline_layout(
    bind_group_layouts=[bind_group_layout]
)

pipeline = device.create_compute_pipeline(
    layout=pipeline_layout,
    compute={
        "module": shader_module,
        "entry_point": "main",
    },
)

WGSL Language

@group(0) @binding(0)
var<storage,read> data0: array<i32>;

@group(0) @binding(1)
var<storage,read_write> data1: array<i32>;

@compute
@workgroup_size(64)
fn main(@builtin(global_invocation_id) index: vec3<u32>) {
    let i: u32 = index.x;
    data1[i] = data0[i] * data0[i];
}

index is marked with @builtin(global_invocation_id) so it will receive the 3 ints thread ID
Here we define how to interpret buffer’s bytes
WGSL syntax is close to the Rust syntax

Bind Group

We must create the Bind Group now

bind_group = device.create_bind_group(
    layout=bind_group_layout,
    entries=[
        {
            "binding": 0,
            "resource": {
                "buffer": buffer0,
                "offset": 0,
                "size": buffer0.size,
            },
        },
        {
            "binding": 1,
            "resource": {
                "buffer": buffer1,
                "offset": 0,
                "size": buffer1.size,
            },
        },
    ],
)

Run the pipeline

We must create and send Commands to the GPU

from wgpu import GPUCommandEncoder, GPUComputePassEncoder

with Timer("Compute Pipeline"):
    command_encoder: GPUCommandEncoder = device.create_command_encoder()

    compute_pass: GPUComputePassEncoder = command_encoder.begin_compute_pass()

    compute_pass.set_pipeline(pipeline)
    compute_pass.set_bind_group(0, bind_group)
    compute_pass.dispatch_workgroups(n // 64, 1, 1)
    compute_pass.end()

    device.queue.submit([command_encoder.finish()])

Get data back

out: memoryview = device.queue.read_buffer(buffer1)
result = np.frombuffer(out.cast("i"), dtype=np.int32)
print(result)

Hands-on

Game of Life
